Products Description
|
Measurer |
|
|
PWM |
880-2200us @ 20-400Hz |
|
PPM |
880-2200us * 8CH @ 20-50Hz |
|
SBUS |
880-2200us * 16CH @ 20-100Hz |
|
voltage |
1.0-5.0V @ 1-8S |
|
Internal resistance |
0.1 mR-99R @ 1-8S |
|
ESC |
600W @ 20A |
|
Charger |
|
|
input voltage |
7.0-35.0V @MAX 25A |
|
battery type |
Lipo LiHV LiFe Lion LTO@1-8S NiMh @1-20S Pb @1-10S |
|
balance current |
1000mA @ 4.2V |
|
charging power |
600W @MAX 20A |
|
discharge power |
600W @MAX 20A Recycle mode 20W@3A Normal mode |
|
USB |
65W@5.0-20.0V or Upgrade by USB-A |
|
Output |
|
|
PWM |
500-2500us @ 20-1000Hz |
|
PPM |
880-2200us * 8CH @ 20-50Hz |
|
SBUS |
880-2200us * 16CH @ 20-100Hz |
|
power supply |
1.0-35.0V @1.0-20A mode:CC CV |
|
Overcurrent response |
<5ms |
|
General |
|
|
Product size |
108*71*36mm |
|
product weight |
235g |
|
packing size |
135*81*44mm |
|
packaging weight |
330g |
|
LCD |
IPS 2.4 inch LCD 320*240 |
Details Images
